SLYWV-75-9 Leaky Feeder Cable , MSHA VHF Mine Leaky Feeder Cable China leaky feeder cable factory
Quick details:
Product description:
MSHA certified leaky feeder cable, Meet IEC1196 and EN50117.
The leaky feeder cable has a radiation pattern of 360 degrees around the cable and can be strapped directly to a centenary cable, water or air pipe. The standard length is 350m or 500m with a yellow outer jacket.
As an option, the cable can be manufactured according to order with a blue color outer jacket and low smoke halogen free jacket is also available.
Applications:
Specification:
NO. | Items | Technical Requirements | |
1 | Inner conductor CU | 2.31±0.03mm | |
2 | Dielectric FPE | 9.50±0.20mm | |
3 | Outer conductor CU | 16*0.60mm | |
4 | Inner jacket PE | 13.0±0.30mm | |
5 | Outer jacket PVC | 15.5±0.50mm | |
6 | impedance | 75±3Ω | |
7 | Frequency | 5-500 MHz | |
8 | DC resistance inner conductor | ≤4.1Ω/km | |
9 | DC resistance outer conductor | ≤3.9Ω/km | |
10 | Capacitance Pf/m | 51±2 | |
11 | Insulation resistance | >10.4Ω/km | |
12 | MIN. bend radius | 150mm | |
13 | Coupling loss(50%), dB | 65±10 | |
14 | Operating temperature | -40 to +70 centigrade | |
15
|
Attenuation@20℃ ≤dB/100m |
85 MHz | ≤3.4dB |
150 MHz | ≤4.2dB | ||
160 MHz | ≤4.8dB | ||
450 MHz | ≤6.1dB |
Competitive Advantage:
