Bare Copper CAT 6E Cable For High Data Rate Network , Lan CAT Cable for Gigabit Ethernet
Applications
Specifications:
conductor |
material |
Bare copper |
Nominal diameter |
23AWG,0.57mm |
|
insulation |
material |
PE |
Nominal diameter |
1.04mm |
|
jacket |
material |
PVC/PE |
Nominal thickness |
0.5mm |
|
Nominal diameter |
5.70mm |
Temperature rating |
-20 centigrade to 60 centigrade |
|
||||
Dielectric breakdown |
2500V |
|
||||
DC resistance /unbalance |
28.6 ohm/1000 Max /5% Max |
|
||||
Characteristics impedance |
100ohm |
|
||||
Other electrical performance |
Frequency (MHZ) |
Attenuation (dB/100m) |
Return loss (dB/100m) |
Pair to pair |
||
NEXT (dB/100M) |
ELEFEXT (dB/100m) |
|||||
1 |
2.0 |
20.0 |
75.3 |
63.8 |
|
|
4 |
3.8 |
23.0 |
66.3 |
51.7 |
|
|
8 |
5.3 |
24.5 |
61.8 |
45.7 |
|
|
10 |
6.0 |
25.0 |
60.3 |
43.8 |
|
|
16 |
7.6 |
25.0 |
57.2 |
39.7 |
|
|
20 |
8.5 |
25.0 |
55.8 |
37.7 |
|
|
25 |
9.5 |
24.3 |
54.3 |
35.8 |
|
|
31.25 |
10.7 |
23.6 |
52.9 |
33.9 |
|
|
62.5 |
15.4 |
21.5 |
48.4 |
30.0 |
|
|
100 |
19.8 |
20.1 |
45.3 |
29.0 |
|
|
155 |
25.2 |
18.8 |
42.4 |
28.10 |
|
|
200 |
29.0 |
18.0 |
40.8 |
27.80 |
|
|
250 |
32.9 |
17.3 |
39.3 |
23.80 |
|
|
400 |
40.8 |
16.9 |
39.3 |
18.80 |
|
