Anti-Interference RG216 Cable, 75 Ohm Coaxial Cable With Bare Stranded Copper Wire
Product description:
Stranded copper wire as inner conductor, dielectric core is insulating grade virgin polyethylene. 90% Aluminum wire braid, PVC jacket.
Center conductor:
Bare stranded copper wire
7 x 0.39 solid copperØ1.2mm
Dielectric:
solid polyethylene
Nominal diameter over dielectric: 7.11mm+/-0.13mm(0.28 inches)
Shield: bare copper wires with 90% coverage.
PVC Jacket:
Nominal diameter over jacket: 10.8mm+/-0.15mm (0.425 inches)
Jacket thickness: 1.05mm
Electrical properties:
Impedance: 75±3 ohms
Velocity of propagation: 66% nominal
SRL: 22dB
Attenuation@ 68OF(20oC):
@Frequency MHZ |
dB/100 meters(MAX.) |
10 |
1.80 |
100 |
6.50 |
400 |
14.10 |
1000 |
25.20 |
2000 |
43.00 |
3000 |
59.00 |
Applications:
RG216 cable is used as a distribution cable for indoor CATV, CCTV systems and as a connection cable for satellite systems where lower attenuation required.
