12D-FB Coaxial Cable with PE Jacket , Braided 50 ohm Cable for 3G GSM CDMA Telecom System

Large Image : 12D-FB Coaxial Cable with PE Jacket , Braided 50 ohm Cable for 3G GSM CDMA Telecom System Get Best Price

Product Details:

Place of Origin:	China
Brand Name:	Libo
Certification:	CE, ISO9000, ISO14001,RoSH, Certificate of Network access of Broadcast equipment, State Administrati
Model Number:	12D-FB coaxial cable

Payment & Shipping Terms:

Minimum Order Quantity:	0.1KM
Price:	Call or e-mail to get the latest price
Packaging Details:	100/200m/305/1000FT or according to client’s request
Delivery Time:	Within 2 weeks
Payment Terms:	T/T, L/C,DP
Supply Ability:	8,000KM per month

Contact Now

Detailed Product Description

High Light:

LMR coaxial cable

50 ohm coaxial cable

12D-FB Coaxial Cable with PE Jacket , Braided 50 ohm Cable for 3G GSM CDMA Telecom System

10D-FB coaxial cable, bare copper as inner conductor, Dielectric core is insulating grade virgin polyethylene, AL foil+ tinned copper wire as shield, PVC or PE for outer jacket.

Applications

10D-FB coaxial cable is used in 3G, GSM, and CDMA telecommunication system, digital microwave communication system, and aeronautics and space industry, precise instrument.

Specifications:

construction	Testing item			Unit	Standard
	Inner conductor	material		-	Bare Copper
	Inner conductor	diameter		mm	4.40+/-0.01
	Dielectric	material		-	foamed PE
	Dielectric	diameter		mm	12.40mm
	1^st shield, tape	material		-	BAPA
	2^nd shield, braid	material		-	Tinned copper wire
Electrical properties	2^nd shield, braid	coverage		%	85%
	jacket	PVC		mm	15.60+/-0.2mm
	Nominal velocity of propagation			%	81%
	Capacitance			pF/M	84
	Characteristic impedance			Ω	50 +/-3
	V.S.W.R				1.25
	Attenuation 20℃(max)		150MHZ	dB/100m	3.60
			200MHZ		4.20
			280MHZ		4.60
			350MHZ		5.20
			400MHZ		6.00
			800MHZ		8.30
			900 MHZ		9.30
			1200 MHZ		10.70
			1500 MHZ		11.80
			1900 MHZ		13.80
			2000 MHZ		14.40
			2400 MHZ		15.90
			3000 MHZ		18.30

Competitive Advantage:

Libo cable was established in 1994, it covers over 340,000 square meters on our operating area.
Libo cable has a stable workforce and engineering team, our production and testing procedures are all strictly follow requirement of ISO9000, and ISO14000.
Libo cable is equipped with a Provincial-level Research and Development Center; we offer OEM and ODM services.
